用 Kafka 和 Awaitility 测试 Spring Boot 应用

（给ImportNew加星标，提高Java技能）

编译：ImportNew/覃佑桦

dzone.com/articles/testing-spring-boot-asynchronous-application-using

本文介绍了使用 EmbeddedKafka 和 Awaitility 测试 Spring Boot 应用的不同方法。

测试同步调用程序时，主要工作是“调用并等待”。调用指定 API 或 endpoint，然后等待响应。测试代码会阻塞主线程执行，直到 API 返回响应结果。处理完成后，把得到的响应与预期结果进行比较。

与同步程序或阻塞式调用的程序相比，异步程序的测试方式有所不同，无需阻塞主线程执行。简单地说，异步程序不会等待 API 响应。我们需要手动处理测试代码让执行保持在某个执行节点，并等待所有非阻塞操作的执行结果。在这个阶段可以使用断言。

管理不同的线程与并发问题，编写简洁易读的单元测试并非易事。

可以通过几种方式为 Spring Boot 编写测试：用 Kafka 与 Spring Cloud Stream 的微服务连接。

让我们设计一个简单的例子。

示例

producer bean 向 Kafka topic 发送消息。

package com.techwording.scs;
import org.springframework.cloud.stream.annotation.EnableBinding;
import org.springframework.cloud.stream.messaging.Source;
@EnableBinding(Source.class)
public class Producer {
    private Source mySource;
    public Producer(Source mySource) {
        super();
        this.mySource = mySource;
    }
    public Source getMysource() {
        return mySource;
    }
    public void setMysource(Source mysource) {
        mySource = mysource;
    }
}

consumer bean 会监听 Kafka topic 并接收消息。

@EnableBinding(Sink.class)
public class Consumer {
        private String receivedMessage;
        @StreamListener(target = Sink.INPUT)
        public void consume(String message) {
            receivedMessage = message;
            latch.countDown();
        }
        public String getReceivedMessage() {
            return receivedMessage;
        }
    }

创建 topic 对应的 Kafka broker。在这个测试中，通过 spring-kafka-test 创建嵌入式 Kafka server。

@ClassRule public static EmbeddedKafkaRule embeddedKafka = new EmbeddedKafkaRule(1, true, TOPIC1);

EmbeddedKafkaRule

Spring-kafka-test 提供了一个嵌入式 Kafka broker。可以使用 JUnit @ClassRule 注解创建 Kafka broker。该规则会在测试执行之前在随机的端口上启动 Kafka 与 Zookeeper 服务器，并在测试完成后将其关闭。嵌入式 Kafka broker 无需在运行测试时提供真实的 Kafka 和 Zookeeper 实例。

这里提供了两种实现方式：一种使用 Awaitility，另一种使用 countdown latch。

使用 Awaitility 测试

Awaitility 是一个 DSL 开发库，可以为异步 Java 程序开发 Junit 测试。可以在这里了解其官方 GitHub。下面是使用 Awaitility 实现的测试。

package com.techwording.scs;
import java.util.concurrent.TimeUnit;
import org.junit.BeforeClass;
import org.junit.ClassRule;
import org.junit.Test;
import org.junit.runner.RunWith;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.boot.test.context.SpringBootTest;
import org.springframework.cloud.stream.annotation.EnableBinding;
import org.springframework.cloud.stream.annotation.StreamListener;
import org.springframework.cloud.stream.messaging.Sink;
import org.springframework.cloud.stream.messaging.Source;
import org.springframework.cloud.stream.test.binder.TestSupportBinderAutoConfiguration;
import org.springframework.kafka.test.rule.EmbeddedKafkaRule;
import org.springframework.messaging.support.MessageBuilder;
import org.springframework.test.context.junit4.SpringRunner;
import static org.assertj.core.api.BDDAssertions.then;
import static org.awaitility.Awaitility.waitAtMost;

@RunWith(SpringRunner.class)
@SpringBootTest(classes = { EmbeddedKafkaAwaitilityTest.App.class, EmbeddedKafkaAwaitilityTest.Producer.class, EmbeddedKafkaAwaitilityTest.Consumer.class })
@EnableBinding(Source.class)
public class EmbeddedKafkaAwaitilityTest {
    @SpringBootApplication(exclude = TestSupportBinderAutoConfiguration.class)
    static class App {
    }
    private static final String TOPIC1 = "test-topic-1";

    @ClassRule
    public static EmbeddedKafkaRule embeddedKafka = new EmbeddedKafkaRule(1, true, TOPIC1);

    @BeforeClass
    public static void setup() {
        System.setProperty("spring.cloud.stream.kafka.binder.brokers",
            embeddedKafka.getEmbeddedKafka()
                .getBrokersAsString());
        System.setProperty("spring.cloud.stream.bindings.input.destination", TOPIC1);
        System.setProperty("spring.cloud.stream.bindings.input.content-type", "text/plain");
        System.setProperty("spring.cloud.stream.bindings.input.group", "input-group-1");
        System.setProperty("spring.cloud.stream.bindings.output.destination", TOPIC1);
        System.setProperty("spring.cloud.stream.bindings.output.content-type", "text/plain");
        System.setProperty("spring.cloud.stream.bindings.output.group", "output-group-1");
    }

    @Autowired
    private Producer producer;

    @Autowired
    private Consumer consumer;

    @Test
    public void testMessageSendReceive_Awaitility() {
        producer.getMysource()
            .output()
            .send(MessageBuilder.withPayload("payload")
                .setHeader("type", "string")
                .build());
        waitAtMost(5, TimeUnit.SECONDS)
            .untilAsserted(() -> {
                then("payload").isEqualTo(
                    EmbeddedKafkaAwaitilityTest.this.consumer.getReceivedMessage());
            });
    }
}

使用 CountDownLatch 进行测试

根据 Java 文档的描述，CountDownLatch 可以让多个线程保持等待，直到其它线程中一组操作执行完毕。要用 CountDownLatch 编写测试，首先要用 counter 初始化 latch。

counter 值取决于测试需要等待的任务数。这里把 counter 初值设为1。一旦 producer 消息发送完毕，latch 会等待 count 变为0。consumer 负责减小 count。当 consumer 完成自己的工作，主线程将恢复运行并执行断言。

下面是用 CountDownLatch 实现的测试：

package com.techwording.scs;
import java.util.concurrent.CountDownLatch;
import org.junit.BeforeClass;
import org.junit.ClassRule;
import org.junit.Test;
import org.junit.runner.RunWith;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.boot.test.context.SpringBootTest;
import org.springframework.cloud.stream.annotation.EnableBinding;
import org.springframework.cloud.stream.annotation.StreamListener;
import org.springframework.cloud.stream.messaging.Sink;
import org.springframework.cloud.stream.messaging.Source;
import org.springframework.cloud.stream.test.binder.TestSupportBinderAutoConfiguration;
import org.springframework.kafka.test.rule.EmbeddedKafkaRule;
import org.springframework.messaging.support.MessageBuilder;
import org.springframework.test.context.junit4.SpringRunner;
import static org.assertj.core.api.Assertions.assertThat;

@RunWith(SpringRunner.class)
@SpringBootTest(classes = { EmbeddedKafkaLatchTest.App.class, EmbeddedKafkaLatchTest.Producer.class, EmbeddedKafkaLatchTest.Consumer.class })
@EnableBinding(Source.class)
public class EmbeddedKafkaLatchTest {
    @SpringBootApplication(exclude = TestSupportBinderAutoConfiguration.class)
    static class App {
    }

    private static final String TOPIC1 = "test-topic-1";

    @ClassRule
    public static EmbeddedKafkaRule embeddedKafka = new EmbeddedKafkaRule(1, true, TOPIC1);

    private static CountDownLatch latch = new CountDownLatch(1);

    @BeforeClass
    public static void setup() {
        System.setProperty("spring.cloud.stream.kafka.binder.brokers",
            embeddedKafka.getEmbeddedKafka()
                .getBrokersAsString());
        System.setProperty("spring.cloud.stream.bindings.input.destination", TOPIC1);
        System.setProperty("spring.cloud.stream.bindings.input.content-type", "text/plain");
        System.setProperty("spring.cloud.stream.bindings.input.group", "input-group-1");
        System.setProperty("spring.cloud.stream.bindings.output.destination", TOPIC1);
        System.setProperty("spring.cloud.stream.bindings.output.content-type", "text/plain");
        System.setProperty("spring.cloud.stream.bindings.output.group", "output-group-1");
    }

    @Autowired
    private Producer producer;

    @Autowired
    private Consumer consumer;

    @Test
    public void testMessageSendReceive() throws InterruptedException {
        producer.getMysource()
            .output()
            .send(MessageBuilder.withPayload("payload")
                .setHeader("type", "string")
                .build());
        latch.await();
        assertThat(consumer.getReceivedMessage()).isEqualTo("payload");
    }
}

在这里可以下载完整源代码。

github.com/nakulshukla08/techwording/tree/master/spring-cloud-stream-kafka-example
